Triple Pole Circuit Breaker (TPC6-6 (6A,6KA))
Stay protected with the LAXFO Double Pole Circuit Breaker, built to handle everyday electrical challenges with confidence. It quickly responds to overloads and short circuits while allowing safe control and isolation of power. With a 6-amp rating and durable IP20 protection, it ensures steady performance in homes or offices. Engineered for long life and reliability, this breaker combines safety, fire resistance, and convenience to keep your electrical system secure and worry-free for years.
Price
Tk.675
Specifications
| Rated current In (A): | 6 A |
|---|---|
| Rated voltage Un (VAC): | 230/400 VAC |
| Rated frequency (Hz): | 50/60 Hz |
| Rated impulse withstand voltage (Uimp): | 4KV |
| Rated short-circuit capacity (A): | 6 KA |
| Rated insulation voltage (VAC): | 500 V |
| Number of poles: | 3 |
| Tripping Curve: | C |
| Thermal operating limit (In): | 1.13 -1.45xIn |
| Degree of protection: | IP20, with connected conductors |
| Electrical life (times): | 10,000 |
| Mechanical life (times): | 20,000 |
| Mounting position: | Any |
| Fire resistance according to UL 94: | V0 |
| Standards: | IEC 60898-1 |
High Breaking Capacity
Overload & Short-Circuit Protection
Fire-Resistant Housing
Reliable Trip Mechanism
